High Quality Heat Insulation Material Class 1 Elastomeric Rubber Foam Sheet for Waiil Insulation

High Quality Heat Insulation Material Class 1 Elastomeric Rubber Foam Sheet for Waiil Insulation

Overview Package Size0.10cm * 0.10cm * 0.10cm Package Gross Weight0.010kg Our Main Rubber Foam Products All products wil
SHARE

Description

  • Overview
  • Product Description
  • HUAYUE Company Profile
  • Why Choose Us!!!!
  • Certifications
  • Quality Control
  • Packaging and Shipping
  • FAQ
Overview
Basic Info.
Model NO. HYUEFLEX RFS1
Material Rubber And Plastic Insulation, NBR and PVC
Color Black
After-Sales Service Online Technical Support, Return and Replacement
Warranty More Than 5 Years
Refractoriness -40-110 Degree Centigrade
Diameter N/M
Apparent Density Adjust According to The Specification
Surface Treatment N/M
Usage Pipelines and Equipments Insulation
Length 4-30m
Width 1m/1.2m
Thickness 9-50mm
Certificate CE/BS476/FM/Asnz/ISO
Application Central Air Conditioning Insulation
Performance Advantages Cold Insulation Moisture Resistance
Category Rubber Foam Sheet
MOQ 5000m2
Thermal Conductivity Less Than 0.036
Features Waterproof, Fireproof
Combustion Performance B Class Flame Retardant
Delivery Time 7-10 Days After Your Prepayment
Customization Service Support
Production Visualization Service Support
Sample Service Support
Transport Package Plastic Bags. Carton.
Specification Customized OEM Available
Trademark HUAYUE
Origin Tianjin China
HS Code 4009110000
Production Capacity 1700000m3 Every Year
Packaging & Delivery
Package Size0.10cm * 0.10cm * 0.10cm Package Gross Weight0.010kg
Product Description

High Quality Heat Insulation Material Class 1 Elastomeric Rubber Foam Sheet for Waiil Insulation

Our Main Rubber Foam Products

High Quality Heat Insulation Material Class 1 Elastomeric Rubber Foam Sheet for Waiil Insulation

High Quality Heat Insulation Material Class 1 Elastomeric Rubber Foam Sheet for Waiil Insulation

All products will have been strictly quality checked in house before packing. All products will be well packed before shipping. We accept OEM and ODM.

High Quality Heat Insulation Material Class 1 Elastomeric Rubber Foam Sheet for Waiil Insulation

High Quality Heat Insulation Material Class 1 Elastomeric Rubber Foam Sheet for Waiil Insulation

Product Description

Brief Introduction of Rubber Foam
The rubber foam products of our company are produced by imported high-end technology and automatic continuous equipment. We have developed a rubber foam insulation material with excellent performance through in-depth research. The major raw materials we use are NBR/PVC. The main characteristics are: low density, close and even bubble structure, low thermal conductivity, cold resistance, extremely low water vapor transmissibility, low water absorbtive capacity, great fireproof performance, superior anti-age performance, good flexibility, stronger tear strength, higher elasticity, smooth surface, no formaldehyde, shock absorption, sound absorption, easy to install. The product is suitable for a wide range of temperature from -40ºC to 120ºC.
Our Class0/1 insulation is generally black in color, other colors are available upon request. The product comes in tube, roll and sheet form. The extruded flexible tube are specially designed to fit the standard diameters of copper, steel and PVC piping. Sheets are available in standards precut sizes or in rolls.

· Rubber Foam Technical Performance

High Quality Heat Insulation Material Class 1 Elastomeric Rubber Foam Sheet for Waiil Insulation

Technical Data
Item Unit Specification Standard
Density range Kg/m3 40-85 GB/T 6343
ASTM D1667
Flammability Oxygen index % ≥32 GB/T 2406
SDR - ≤75 GB/T 8627
Fire Rating - Class 0 & Class 1 BS 476 Part 6 & Part 7
Conductivity factor
-Average temperature
-20ºC W/(M·K) ≤0.030 GB/T 10294
ASTM C518
0ºC ≤0.032
40ºC ≤0.036
Water vapor Permeability Coefficient g/(m·s·pa) ≤2.8 X 10-11 GB/T 17146
Factor - ≥10000
Water adsorption ratio in vacuum % ≤4 GB/T 17794
Dimension stability (105ºC±3ºC, 7d) % ≤5 GB/T 8811
ASTM C534
Crack resistance N/cm ≥3.0 GB/T 10808
Comperssion resilience ratio(Comperssion ratio 50%, Comperssion time 72h) % ≥70 GB/T 10808
Anti-ozone(Ozone pressure 202mpa 200h) - Not cracking GB/T 7762
Aging resistance (150h) - Slightly crumpling, no cracks, no pin holes, not eforming GB/T 16259
Flexibility - Excellent ASTM D1056
Temperature ºC -50 - 120 GB/T 17794
Products type Pipe & sheet
Color Black, gray and other colors
Regular size Pipe: inner diameter 6-108mm
Sheet: thickness 10-30mm
Packing PE plastic bags / exported standard carton
Diversified packaging to meet your needs
Specification of Rubber Foam Sheet
Thickness 6mm 10mm 15mm 20mm 25mm 30mm 32mm 40mm
Length 30m 20m 10m/16m 8m/10m 8m/10m 8m/10m 6m 5m
Width 1m/1.2m
Note: 1.The above specifications are commonly used specifications. Special specifications are available according to request of customer. 2. Rubber foam sheet and pipe are normally in black. Other colors are available according to requirements of customer. 3. It is recommended to use sheet when outer diameter of pipe exceeds 89mm. 4. Multiple layers packing is recommended where the thickness of heat insulation materials which you need are greater than 25mm. 5. The width of the sheet can be customized to 1-2 meters according to customer's requirements.
Veneer of Rubber Foam Sheet
Applications of Rubber Foam Sheet

Rubber foam insulation materials are widely in multiple scenes for thermal insulation and noise reduction, which are used in various pipes and equipment, such as central air conditioning, air conditioning units, construction, chemical, medicine, electrical appliances, aerospace, auto industry, thermal power etc.

HUAYUE Company Profile

Why Choose Us!!!!

1. Full series thermal heat insulation products, inculding cellular glass insulation, rubber foam insulation, glass wool insulation, rock wool insulation, XPS, etc.;
2. Stock sale, place the order and delivery immediately for the regular specification;
3. Top quality in the China thermal heat insulation supplier and manufacturer;
4. Reasonable and competitive price, fast lead time;
5. Deliver customized whole solution package to our customer. Welcome to contact us and visit our company and factories at any time!

Certifications

HUAYUE® Glass Wool insulation materials has obtained many certifications:

· FM · ASTM · BS476 part 6 & part 7 · CE · ISO14001 · ISO9001 · OHSAS18001

Quality Control

HUAYUE maintains a stringent system of QC, in all its operation by its professional QC staff. We have 6 quality control engineers and test chemists.

We have our own test laboratory. HUAYUE glass wool heat insulation has been inspected by HUAYUE's Professional Quality Inspectors.

From each batch of raw materials, mid-products to end insulation materials, whole process would be validated by Huayue's Quality Assurance system. This will assure our customers that all materials have been tested and meet our high standards of quality assurance.

Packaging and Shipping

FAQ

Q: Are you manufacturer or trade company?A: We are professional manufacturer of thermal insulation material, more than 22 Years.

Q: Do you accept sample order?A: Sample order is acceptable. We can offer free sample, sample can be sent within 1~3 days after freight payment confirmed. Q: Does your company and products has any certification to ensure quality? A: We are in compliance with CE, BS476, FM, ISO9001, ISO14001, OHSAS18001 certificate etc. Our products have excellent chemical, physical features and stability; better waterproof and low thermal conductivity.Q: What services can Huayue provide? A: * Any inquires will be replied within 0-1 hours. * We are professional manufacturer. Welcome to visit our company and factories at any time! * Any your idea on the packing we can help you to design and put into production. Customized product is available. * High quality, reasonable and competitive price, fast lead time. * All products will have been strictly quality checked in house before packing. * All products will be well packed before shipping. Sample order prepared, just 3-10 days for arriving at your address.
Q: What is Huayue's inspection process for Glass Wool?A: Raw Material Inspection - Production Process Inspection - Factory Inspection - Parallel Sample Tracking System.Q: What's the delivery time of 1x40HQ container loading order? A: Within 3-20 days after receipt of prepayment.
