Premium Anti

Basic Info.

Usage	General Plastics, Engineering Plastics, Specialty Plastics
Plastic Properties After Heated	Thermoplastic Plastics
Plastic Forming Method	Injection
Color	White
ODM/OEM	Accept
Sample	Avaiable
Grade	Injection
Glass Fiber	5%-60%
Shape	Pellets, Granules, Particle
Transport Package	25kgs/Bag
Specification	654015cm
Trademark	TOPO NEW
Origin	China
HS Code	390740000
Production Capacity	100kgs/Week

Packaging & Delivery

Package Size65.00cm * 40.00cm * 15.00cm Package Gross Weight25.000kg

Product Description

PC polycarbonate light diffusion granule resin for led cover products factory PC(C0110 NA)

Premium Anti-Static Carbon Fiber Material for Electronics Manufacturing

Are you a trading company or manufacturer?

We are a manufacturer.

About Sample?

A 5 KG Free Sample can be offered per your request.

About Material Color?

We can make the material to your appointed color according to Pantone/RAL#.

How does your factory control the quality? Quality is the Priority, we always pay great importance to quality from beginning to end, and we have professional QC for item quality from spare parts to finished goods.

How many days for mass production?

20 days after all artwork and 30% deposit are confirmed.

How can I get the samples? is the sample free?

7-10 days to send free samples by DHL, TNT, and UPS.

GF Reinforced PC compound material is usually filled with 5%-30% glass fiber as a reinforcing agent. After combination, the compound material has excellent toughness, strength, stress crack resistance, high hardness, and heat resistance. It is also dimensionally stable and is able to spray. Materials can meet ROHS environmental requirements, and they are widely used in electronic components, bearing cages, gears, parts and components, automotive parts, and so on. TOPO NEW MATERIAL can provide reliable customized services according to the client's specific requirements.

Product Description		Applications
· Good dimensional stability		· Injection molding
·LED LED light transparent diffusing material		· Good mechanical properties balance
Properties	Test Method	Test Condition	Unit	Typical Values
Physical properties
Specific Gravity	ISO 1183	23ºC	g/cm3	1.2
MI	ISO 1183		g/10min	10
Ash	ISO 3451	800ºC,30min	%	0
Mechanical properties
Tensile Strength	ISO 527	50mm/min	MPa	67
(Break) elongation	ISO 527	50mm/min	%	60
(3.18 mm)Cantilever beam notched impact strength	ASTM D256	23ºC	J/m	640
(3.18 mm)Non-notched impact strength of cantilever beam	ASTM D256	23ºC	J/m	-
Thermal properties
Heat deflection temperature	ISO 75	1.80MPa	°C	125
Melting Point	DSC	-	C
Other properties
Transmittance			%	88
Flammability	UL94	3.2		V2
Note: The data above is a typical value for reference, not a guaranteed value. The data will vary with tool design such as gate type, gate location, gate number, injection molding process, and part thickness. The data will vary with different colors as well. Before using the material, please consult with TOPO NEW Material Co., Ltd.
