Ventech Phenolic Foam Air Ducting Panel

Basic Info.

Trademark	VENTECH / OEM
Origin	China
Production Capacity	20 Containers Per Month for Phenolic Foam Insualte

Product Description

VENTECH Phenolic Foam Air Ducting Panel is suitable for all HVAC ducting.It can be farbicated into different kinds of shapes by cutting and adhesive connecting.Compared with the GI ducting,phenolic pre-insulated duct panel has the advantage of low weight,fast installation,fire-resistant,sound insulation and energy saving.
Our phenolic pre-insulated duct panel is made of 2 layers of aluminium foil at both side and 1 layer of phenolic foam in the middle.

Phenolic Board Specification
Length	3950/3900m
Width	1200m
Thickness	20,25,30mm
Thermal conductivity	0.030W/m.k
Density	55-65kg/m³
Compressive Strength	0.31Mpa
Water Absorption	0.60%
Dimension Stability	0.20%
Operating Temperature Limits	-25°C to 80°C
Application	Indoor
Fire and smoke performance	ASTM E84
Combustibility Property	Class 0

VENTECH phenolic pre insulated foam board duct board is manufactured from Phenolic Foam Pre-insulated Duct Panels and Accessories by a set of special tools. The Panels consist of panel thickness 20mm, with double-faced 60um aluminium foil, both sides faced with aluminum foil, aluminum sheet, etc.

Ventech Phenolic Foam Air Ducting Panel

VENTECH phenolic pre insulated foam board duct board is accomplished by following a standardised procedure. The process is the same regardless of the shape of the duct element: tracing, cutting, gluing, folding, taping, flangeing & reinforcement and sealing.
VENTECH phenolic pre insulated foam board duct board is widely used in the ventilation systems of central air conditioning units in hotel, supermarket, airport, stadium, workshop, food store, industry and so on.

Ventech Phenolic Foam Air Ducting Panel

Product Features:
1.panel thickness 20mm, with double-faced fiberglass aluminum foil.
